API 598 Flanged Pipeline Ball Valve

Brand Name : VT

Certification : API 6D, API 607,TS, ISO 9001,

Place of Origin : Zigong,Sichuan,China

MOQ : 1 Set

Price : negotiated

Payment Terms : L/C, T/T

Supply Ability : 10000 Set Per Year

Packaging Details : Plywood Case

Name : Two Sets Modular Type Four Way BALL Valve

Used : material and liquid mixing and distribution

Feature : Two Sets Modular Type

Port : Four Way

Inspection : API 598

End Connection : Flange

Contact Now

Two Sets Modular Type Four Way BALL Valve Is An Ideal Accessory Product For Filters

Product Description

In the power station system known as two-way water supply rotary valve (also known as air reversing valve in petrochemical system), suitable for liquid, gas, dust, slurry and solid particle medium circulation system. Four-way ball valve is adopted to replace the working principle of the manifold and valve group of the process, which simplifies procedures, facilitates operation, reduces costs, facilitates control and has good synchronization

Technical Parameters

Design standard	API6D
Connection ends	flange
Operation	Manual,Pneumatic,Electric,Gas-liquid interaction etc.
Nominal diameter	2” – 20” (DN 50-DN 500)
Pressure range	CLASS 150 – CLASS 900 (Mpa 1.6- Mpa 15.0)
Materials	carbon steel,stainless steel,20#steel ,Nickel alloy,Cobalt alloy
Inspection and Test	API 598

Feature

Four Way Ball Valve Integrated structure, less flange connection, high reliability,low piping stress.

Use anti-static and anti-off device design.

Can lock the switch position for preventing misoperation.

Designed light weight.

Application

Suitable for petroleum, chemical, pharmaceutical and other industries of a variety of material and liquid mixing and distribution, its applicable temperature, pressure and medium properties can be designed and manufactured according to different needs of users.
